Print Position Command
[ESC+H] Horizontal Print Position
[ESC+V] Vertical Print Position
Parent topic Part 1 SBPL Commands
[ESC+H] Horizontal Print Position
ESC H ParameterHexadecimal code
<1B>
16
<48>
16
aaaa
Initial value aaaa=1
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter is valid until the next valid setting.
Valid range and term of
command
Valid range between items The set parameter becomes initial value at the next item
<A>.
[Function]
Specifying horizontal print position from its start point by dot.
[Format]
<H>aaaa
• Parameter
a [Horizontal Print Position] = Refer to the table below.
[Coding Example]
Horizontal print position: 200 dots
<A>
<V>100
<H>200<P>2<L>0202<XM>ABCD
<Q>2
<Z>
[Supplementary Explanation]
• Specifying the start of horizontal position for the print of text, barcode, ruled line and graphic.
[Note]
• Any contents such as text, barcode, graphic exceed printing area will not be printed.
[Initial Value and Valid Range of Parameter]
Model Head density Initial value Valid range (dots)
203 dpi 1 1 to 832
305 dpi 1 1 to 1248
CL4NX
609 dpi 1 1 to 2496
CL6NX 203 dpi 1
1 to 1216
*1
