[ESC+F] EPC sequential number (UHF M6e) (CL4NX Only)
Command ESC F Parameter
Hexadecimal code <1B>
16
<46>
16
aaaabccc(,dd,ee,f)
Initial Value Nil
When turning off the power The set command is not maintained.
Valid range within item The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
This command is set before EPC code write (<IP0> command), and is used to write the sequential
number of the specified data.
[Format]
<F>aaaabcccc(,dd,ee,f)
• Parameter
aaaa “Number of printing for the same contents” = Valid range
：
1 to 9999
b “Increment/decrement setting”
+ : Addition
- : Subtraction
cccc “Increment/decrement value setting” = Valid range : 1 to 9999
dd “Sequential numbering digits” = Valid range : 1 to 24 24 if omitted (can be omitted)
ee “Lower disabled digits” = Valid range : 0 to 99 0 if omitted (can be omitted)
f “Decimal or HEX serial number”
0 : Decimal 0 if omitted (can be omitted)
1 : HEX
[Coding Example]
Number of printing for the same contents: 1, Increment/Decrement: +, Increment/decrement value:
1, Sequential numbering digits: 5
Lower disabled digits: 0
<A>
<V>100<H>100<P>2<L>0202
<F>1+1,5,0<IP0>e:h,epc:0123456789ABCDEF01200000;
<Q>2
<Z>
[Supplemental explanation]
• The EPC sequential number location in one item is one location.
• Inverse printing <(> of the sequential number data cannot be used.
• Automatic line feed <E> cannot be used.
• EPC sequential numbering is enabled only if specified immediately before EPC code write
(<IP0> command).
• This command cannot be used in items that include the <TU> command.
