422
Partition
value
Number of digit of the company prefix Number of digit of the item reference
4 8 5
5 7 6
6 6 7
In the case shown in this example, the following combination is assumed:
Number of digits of the company prefix: 6
Number of digits of item reference: 7
If both items combined together do not form 13 digits, 0 is entered before the number to fill up
the lacking number of digits.
The partition value is 6, but since this value is generated within the PC, it need not be specified.
Under this condition, if the format of <IPO> EPC code write is applied, it results in the following:
◦ When the standard format is used
<IP0>e:h,enc:c,com:003885,itm:4006606,flt:0,srl:000000000001;
Description of each parameter
e:h, --------------- Specifies the standard format
enc:c, ------------- Specifies SGTIN96 code conversion
com:003885, -------- The company prefix is 6 digits
itm:4006606, ------- The item reference is 7 digits 13 digits when combined with com:
flt:0, ------------- The filter value is All Others
srl:000000000001 --- Serial number, fixed at 12 digits 274877906943 or a smaller number.
;------------------ End terminal
◦ When the one-character parameter identifier in the conventional format is used
<IP0>e:c,c:6,t:7,f:0,d:0038854006606,n:000000000001;
Description of each parameter
e:c, -------------- Specifies SGTIN96 code conversion
c:6, -------------- The company prefix is 6 digits
t:7, -------------- The item reference is 7 digits 13 digits when combined with c:
f:0, -------------- The filter value is All Others
d:0038854006606, - Number in which the company prefix and item reference are joined
together It is 13 digits.
n:000000000001 ---- Serial number, fixed at 12 digits 274877906943 or a smaller number.
;----------------- End terminal
When these commands are executed, the above parameters are converted to SGTIN96 code
301803CB4F48B38000000001 and 24 characters, and are written in a tag.
