421
Partition
value
Number of digit of the company prefix Number of digits of the serial reference
5 7 10
6 6 11
In the case shown in this example, the following combination is assumed:
Number of digits of the company prefix: 7
Number of digits of serial reference: 10
The partition value is 5, but since this value is generated within the PC, it need not be specified.
Under this condition, if the format of EPC code writes <IPO> is applied, it results in the
following:
◦ When the standard format is used
<IP0>e:h,enc:a,com:4011661,srl: 3000000001,flt:0;
Description of each parameter
e:h, ------------- Specifies the standard format
enc:a ------------ Specifies SSCC96 code conversion
com:4011661, ----- The company prefix is 4011661
srl:3000000001, -- The serial reference is 3000000001 17 digits when combined with com:
flt:0 ----------- The filter value is All Others
; ---------------- End terminal
◦ When the one-character parameter identifier in the conventional format is used
<IP0>e:a,c:7,s:10,f:0,d:40116613000000001;
Description of each parameter
e:a, -------------- Specifies SSCC96 code conversion
c:7, -------------- The company prefix is 7 digits
s:10, ------------- The serial reference is 10 digits 17 digits when combined with c:
f:0, -------------- The filter value is All Others
d:40116613000000001 - Number in which the company prefix and serial reference are
joined together It is 17 digits.
; ----------------- End terminal
When these commands are executed, the above parameters are converted to SSCC96 code
3114F4DA34B2D05E01000000 and 24 characters (18 characters in actuality), and are written in
a tag.
• SGTIN96 code conversion
This function is used to generate a code according to the SGTIN96 standard when a company
prefix, item reference, filter value, and serial number are applied. For the time being, the usage
method is explained by using an example in which the following numbers have been applied. All
numbers below are in decimals.
Company prefix: 003885
Item reference: 4006606
Filter value: 0(Select the filter value from the filter value standard table described earlier
according to the purpose of use. In this example, the filter value is 0 from “All Others”)
Serial number: 000000000001(fixed as 12 digits)
According to the standard, the company prefix and item reference are combined together
to result in 13 digits. Of these 13 digits, the proportion of the company prefix and the item
reference can be selected from the seven combinations described in the table below.
Partition
value
Number of digit of the company prefix Number of digit of the item reference
0 12 1
1 11 2
2 10 3
3 9 4
To Next Page
