SATO CL6NX Programming Reference

420
Example 1 Example 2 Example 3
When EPC
code write
has failed
Print tag error
Retry operation
Six short beeps Print tag error
Retry operation
• Buzzer will sound in the following manner.
EPC code write success/fail will be notified with the following buzzers only when EPC code write
is specified without print data:
◦ EPC code write is successful: Two short buzzer sounds
◦ EPC code write fails: Six short buzzer sounds
Buzzer sound for successful EPC code write can be changed according to settings under
System->Sound->Error Sound.
• Unused parameters can be omitted.
• For details on the filter value to be used with SSCC96/SGTIN96, refer to the table below
according to the purpose of use.
Filter value standard table
Filter value SSCC96 SGTIN96
0 All Others All Others
1 Reserved Point of Sale (POS) Trade Item
2 Full Case for Transport Full Case for Transport
3 Reserved Reserved
4 Reserved Inner Pack Trade Item Grouping for Handling
5 Reserved Reserved
6 Unit Load Unit Load
7 Reserved Unit inside Trade Item or component inside a
product not intended for individual sale
• SSCC96 code conversion
This function is used to generate a code according to the SSCC96 standard when a company
prefix, serial reference, and filter value are applied. For the time being, the usage method is
explained by using an example in which the following numbers have been applied. All numbers
are in decimals.
Company prefix: 4011661
Serial reference: 3000000001
Filter value: 0(Select the filter value from the filter value standard table described earlier
according to the purpose of use. In this example, the filter value is 0 from “All Others”)
According to the standard, the company prefix and serial reference are combined together
to result in 17 digits. Of these 17 digits, the proportion of the company prefix and the serial
reference can be selected from the seven combinations described in the table below.
Partition
value
Number of digit of the company prefix Number of digits of the serial reference
0 12 5
1 11 6
2 10 7
3 9 8
4 8 9

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
