419
When free mapping data is written in the EPC area of a Gen2 corresponding tag
<A>
<V>50<H>50<BD>101080*301803CB4F48B38000000001*
<IP0>e:z,d:301803CB4F48B38000000001;
<Q>1
<Z>
[Coding example 4]
When data is written in free mapping in the EPC area of a Gen2 corresponding tag, data is written in
the user area, and at the same time, a permanent lock is applied to both the EPC and USER areas
<A>
<V>50<H>50<BD>101080*0123456789ABCDEF01234567*
<IP0>e:z,d:0123456789ABCDEF01234567,u:0123456789ABCDEF0123456789ABC
DEF0123456789ABCDEF,m:10001;
<Q>1
<Z>
[Coding example 5]
When data is written in free mapping in the EPC area of a Gen2 corresponding tag, and a password
lock is applied to the EPC area. When the password is set as 12345678
<A>
<V>50<H>50<BD>101080*0123456789ABCDEF01234567*
<IP0>e:z,d:0123456789ABCDEF01234567,a:12345678,m:00101;
<Q>1
<Z>
[Supplemental explanation]
•
This command can be used only once between the data transmit start <A> to the data transmit
end <Z>.
• When print data is to be included beside EPC code write, multiple labels can be specified. If
there is no print data as in Example 2, media is not fed. If a blank media is to be fed after EPC
code write, specify feeding without print as in Example 3.
[Example 1] If print data is included, the QTY can be specified.
<A>
<V>50<H>50<XM>0123456789ABCDEF01234567
<IP0>e:z,d:0123456789ABCDEF01234567;
<Q>1
<Z>
[Example 2] If you specify EPC code write without print data, the media is not fed, and QTY
cannot be specified.
<A>
<IP0>e:z,d:0123456789ABCDEF01234567;
<Z>
[Example 3] If there is no print data, but you have specified feeding without print in EPC code
write, the media is fed, and QTY can be specified.
<A><IP0>e:z,d:0123456789ABCDEF01234567,g:1; <Q>2<Z>
or
<A><IP0>e:
ｈ,epc:0123456789ABCDEF01234567,fsw:1;
<Q>2<Z> (for the standard format)
Example 1 Example 2 Example 3
When EPC
code write is
successful
Print, feed Don’t feed
Two short beeps
Feed a blank label
To Next Page
