SATO CL6NX Programming Reference

41
Parallel 1 (0-degree) Parallel 2 (180-degree) Serial 1 (90-degree) Serial 2 (270-degree)
Label feed direction
Base ref.
point
Label feed direction
Base ref.
point
Label feed direction
Base ref.
point
Label feed direction
Base ref.
point
[Valid Commands]
<XU> <XS> <XM> <XB> <XL> <OA> <OB> <RD> <$=> <K1>
<K2> <K3> <K4> <K5> <K8> <K9> <KA> <KB> <KD> <k1>
<k2> <k3> <k4> <k5> <k8> <k9> <kA> <kB> <kD> <U>
Font
<S> <M> <WB> <WL> <X20> <X21> <X22> <X23> <X24>
<B> <BC> <BG> <BI> <D> <D><d> <BD> <BT> <BW> <BP>Barcode
<BF> <BS> <BL> <BL><d> <BM>
<2D10> <BK> <2D12> <2D20> <BV> <2D30> <2D31> <2D32> <BQ> 2D code
<2D50> <BX> <2D51> <2D70>
Composite
Symbol
<EU>
Graphic <G> <GM> <GP>
System <E>
Modification <RF> <FW> <FC> <FT> < (>
Memory
card
<GR> <GC> <PY>
Calendar <WA>
*1
*1 This command requires optional calendar IC.
Parent topic Modification Command

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
