SATO CL6NX Programming Reference

545
[Identifier]
Valid range
CA: Common settings
CB: Notification functionality
II: IEEE1284 settings
IR: RS-232C settings
IL: LAN settings
IU: USB settings
IW: WLAN settings
IB: Bluetooth settings
IE: EXT settings
IF: RFID settings
IN: NFC settings
SB: SBPL settings
SZ: SZPL settings
SI: SIPL settings
SD: SDPL settings
ST: STCL settings
SE: SEPL settings
[Setting information data format]
"Setting item name" + ":" + "Setting data" + "Line feed (0DH, 0AH)"
h...h:i...i[CR][LF](j...j:k...k[CR][LF])...
[Setting information data]
Symbol Parameter name Valid range
h(j...) Setting Item name Refer to the list of setting items of [DC2+PA].
i(k...) Setting data Refer to the list of setting items of [DC2+PA].
Data Example)
CA,12345,SPEED:4
LEVEL:5
CONCENTRATION:A
:
[Return data format (when a command error occurs)]
[NAK]<15>
16

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
