Section 05 ENGINE (4-TEC)

Subsection 02 (INTAKE SYSTEM)

4-TEC Supercharged Engines — Intake Manifold and Throttle Body

R1503motr251S

10 Nm

(89 lbfpo)

Loctite 243

Huile

Loctite 243

6 Nm

(53 lbfpo)

18 Nm

(159 lbfpo)

Loctite

243

6 Nm

(53 lbfpo)

10 Nm

(89 lbfpo)

10 Nm

(89 lbfpo)

Huile

smr2004-Complete Line Up 187
