Section 05 ENGINE (4-TEC)

Subsection 02 (INTAKE SYSTEM)

4-TEC Supercharged Intercooled Engines

R1503motr358S

10 Nm

(89 lbfin)

10 Nm

(89 lbfin)

Loctite

243

Loctite 243

6 Nm

(53 lbfin)

Loctite 243

10 Nm

(89 lbfin)

18 Nm

(159 lbfin)

6 Nm

(53 lbfin)

Loctite

243

Oil

188 smr2004-Complete Line Up

www.SeaDooManuals.net
