SeaDoo GTI User Manual

Section 14 STEERING SYSTEM
Subsection 01 (STEERING SYSTEM)
F00K01A
1
GTI SERIES
1. Set screw
GTI Series
Remove 4 screws no. 7.
F00K02A
2
1
TYPICAL
1. Cover
2. Screws
Remove 2 screws no. 20 and flat washers no. 21
each side of cover.
1
F07K0JA
1. Remove screws
Remove cover.
GTX 4-TEC Series and RXP 4-TEC
Remove 2 tapping screws no. 42.
2
F18K0CA
1
1. Tapping screw
2. Handle bar housing
Remove handlebar housing cover no. 8 and throt-
tle handle housing no. 39.
Unhook throttle cable from throttle handle no. 40.
Pry out the throttle cable housing from throttle
handle housing no. 41.
2
F18K0DA
13
1. Throttle cable
2. Throttle handle housing
3. Throttle cable handle
Remove 6 screws no. 7 and flat washers no. 45
each side of cover.
Remove lower steering cover no
.4.
688 smr2004-Complete Line Up
www.SeaDooManuals.net

SeaDoo GTI Specifications

General

Seating Capacity	3
Manufacturer	Sea-Doo
Fuel Type	Gasoline
Fuel Capacity	15.9 gallons
Type	Recreational
