SeaDoo GTI User Manual

Section 14 STEERING SYSTEM
Subsection 01 (STEERING SYSTEM)
1
F18K0EA
2
1. Steering cover
2. Screws
Unscrew DESS switch nut using safety lanyard
switch tool (P/N 529 034 600).
Remove upper steering cover no. 4.
1
F18K0FA
1. DESS switch nut
Steering Padding
Remove steering cover as mentioned above.
Remove 2 screws no. 35 and flat washers no. 36.
Remove steering padding no. 37.
1
2
F18K0GA
1. Screws
2. Steering padding
Handlebar
GTX 4-TEC Supercharged Limited Models Only
Remove 4 elastic stop nuts M8 retaining steering
clamp no. 44.
F07K0SA
12
TYPICAL
1. Remove nuts
2. Steering clamp
Detach steering clamp no. 44 andremovehandle-
bar no. 22. Withdraw rubber pad no. 32 and stop-
per no. 33.
smr2004-Complete Line Up 689
www.SeaDooManuals.net

SeaDoo GTI Specifications

General

Seating Capacity	3
Manufacturer	Sea-Doo
Fuel Type	Gasoline
Fuel Capacity	15.9 gallons
Type	Recreational
