Section 02 MAINTENANCE
Subsection 04 (STORAGE)
F08E0PA
1
XP DI MODELS
1. Water outlet hose underneath tuned pipe
Hose Disconnection
Disconnect the bottom hose at the water regulator
valve on muffler.
F08E0SA
1
XP DI MODELS
1. Disconnect the bottom hose from water regulator valve
Temporarily install a hose of approximately 1 m
(3 ft) with an internal diameter of 12.7 mm (1/2 in)
over the previously disconnected hose.
Antifreeze
Insert a funnel into the temporary hose.
Ensure to hold the funnel approximately 1 m (3 ft)
above the deck when pouring the antifreeze to
create enough pressure so that it flows properly.
F08E0TA
A
A. 1 m (3 ft) to ease antifreeze flow
Pour antifreeze in engine until the colored solution
appears at cooling system bleed outlet.
At this point, install a hose pincher on bleed outlet
hose.
46 smr2004-Complete Line Up
