Section 16 HULL/BODY

Subsection 01 (ADJUSTMENT AND REPAIR)

F18L1QA

1. Storage cover

2. Inner skin

3. Rubber hammer

– Remove connector harness from the inner skin

by cutting tie-raps.

F18L1RA

1. Inner skin

2. Storage cover

3. Connector harness

– Remove compass by removing dart (2).

– Remove temperature sensor from grommet.

F18L1SA

1. Inner skin

2. Temperature sensor

3. Compass

F18L1TA

1. Dart (x 2)

2. Compass

F18L1UA

1. Temperature sensor

2. Grommet

smr2004-Complete Line Up 739
