DMG 3200/3100/3000 – User Manual
Page 237 (306)
Bitrate
Total bitrate (Mbps) that will be shared between all coders in this
StatMux group.
8.7.2.2 StatMux Group Status
The status tab will bring up the group status with the current bitrate allocation. The
following status is available:
Video Bitrate
Bitrate allocated by the video PID in this program.
Activity
Informal measurement of frame-to-frame video activity and estimated
bitrate requirements for this program. A low activity indicates a still picture
while a high activity indicates rapid scene changes. A HD channel will
have a higher video activity (and higher bitrate requirements) than a SD
channel..
Distortion
Informal measurement of video distortion after encoding, based on the
amount of quantization introduced per video frame. A low distortion value
indicates that a low QP and a high VQ was achieved
The statistics can be reset using the Reset Stats button
Figure 8.48 – Statmux Group status
For each bar, the following information is shown:
• Maximum bitrate since last reset
• Current live bitrate
