DMG 3200/3100/3000 – User Manual
Page 77 (306)
System behavior for different combinations of IGMP (version 2 or 3) input configurations:
Sources Source filter Comment
0 Off GUI has not enabled filtering and no source is specified.
1 On
Only the multicast with the matching source address is available on
the input. This does not require IGMPv3
>1 Off
In this mode all IGMPv3 sources are mapped to the same port. I.e. it
is not possible to reuse the MCAST:PORT pair on other inputs
Please note, only one of these sources should be active at a given
time.
IGMPv3/SSM Source filtering is shown in figure below
Figure 5.32 - Edit IP Port for IGMP source filtering
If it is required that multiple sources of the same multicast be enabled concurrently, then these
will need to be subscribed to on unique input ports, each specifying their source IP address.
5.4.5.4 IP Input with FEC
For IP input modules with FEC, the input window has an additional column with a checkbox for
each stream, allowing you to enable FEC.
