098-00564-000 Revision A3 – July, 2013 TimeProvider 2300/2700 User’s Guide 145
Chapter 3
TimeProvider 2300/2700 CLI Command Set
Example 1:
To set the active-profile of PTP master in eth2 port as telecom-2008:
TP2700>set ptp master active-profile eth2 telecom-2008
Example 2:
To provision the following attributes of profile telecom-2008 for PTP master in eth2
port:
ptp state
ttl
dscp
dither
two-step
unicast-negotiation
lease-limit
announce-limit
sync-limit
domain Sets the domain value for the Client clock.
IEEE-1588-2008 defines a domain as a logical grouping of
clocks that synchronize to each other using the protocol,
but that are not necessarily synchronized to clocks in
another domain.
dscp The Differentiated Services Code Point is an 6-bit field in
the 8-bit Differentiated Services (DS) field of the IP packet
header to specify what classes of traffic will be provided,
what guarantees are needed for each class, and how
much data will be sent for each class. When used with the
TP 2300/2700, it provides a way to prioritize packets for
PTP traffic.
QoS code = 0 means no special priority
master-table A list of IP address, priority, and vlan related to acceptable
PTP masters. The address 0.0.0.0 means no Master is
added under this index.
Vlanid = 0 means no vlan
Table 3-5. PTP Client
Parameter Descriptions for Telecom-2008 Profile (Continued)
Parameter Description
