Multi Pro 5800Page 8 − 20GeoLink Spray System
Record Job Details Menu
The job menu (Fig. 20) provides access to the following
sub−menus and screens:
Select Job (existing)
Create Job (new)
Configure Job Regions
Record Job Details
Clear Job Data
Data Exchange Menu
Figure 20
1. Job menu icon
2. Select job icon
3. Create job icon
4. Configure job regions
icon
5. Record job details icon
6. Clear job data icon
7. Data exchange menu
icon
2
1
3
4
5
6
7
Compass Calibration
Accuracy of the GeoLink guidance feature is dependant
on information from the system compass located in the
GPS antenna (AGI−4). Start the five step compass cali-
bration wizard to calibrate the system compass by open-
ing the receiver calibration menu icon and selecting
compass (Fig. 21).
NOTE: See Calibrating the Compass in the Adjust-
ments section of this chapter for additional information.
Figure 21
