3.10 Terms and Data for Servomotors With Gears

3-45

Servomotor Specifications and Dimensional Drawings

(3) Efficiency

The output torque and motor speed produce the following trends in efficiency. The values in the tables, Ratings

and Specifications of SGMH Servomotors with Gears, are at the rated motor torque and rated motor speed.

Output torque Motor speed

Efficiency Efficiency
