YASKAWA Sigma II Series User Manual

5.8 Peripheral Devices
5-65
5
Specifications and Dimensional Drawings of Cables and Peripheral Devices
5.8.6 External Regenerative Resistor
Regenerative resistors for SERVOPACKs are internally or externally mounted as shown in the table below.
Regenerative resistors can be externally mounted on all SERVOPACKs. Connect an external regenerative resis-
tor to the SERVOPACK if regenerative energy exceeds the capacity of the SERVOPACK.
If a regenerative resistor is to be mounted externally, the jumper between B2 and B3 for the internal regenerative
resistor must be removed. Refer to 6.5 Connecting Regenerative Resistors for the selection.
No built-in regenerative resistor is provided to 6 kW or more SERVOPACKs. Be sure to prepare the externally
mounted regenerative resistor.
The following table shows examples of regenerative resistors.
* 1. The values in parentheses are for the optional JUSP-RA04 Regenerative Resistor Unit.
* 2. The values in parentheses are for the optional JUSP-RA05 Regenerative Resistor Unit.
Applicable SERVOPACK
SGDM-
Specifications for a Regenerative
Resistor Mounted in a
SERVOPACK
Min. Allowable
Resistance
(Ω)
Resistance (Ω) Capacity (W)
Single-phase 100 V
A3BD, A3BDA
−−40
A5BD, A5BDA
01BD, 01BDA
02BD, 02BDA
Single-phase 200 V
A3AD, A3ADA
−−40
A5AD, A5ADA
01AD, 01ADA
02AD, 02ADA
04AD, 04ADA
Three-phase 200 V
05AD, 05ADA
50 60 40
08AD, 08ADA
10AD, 10ADA
15AD, 15ADA
30 70 20
20AD, 20ADA
25 140 12
30AD, 30ADA
12.5 140 12
50ADA
8 280 8
60ADA
(6.25)
∗1
(880)
∗1
5.8
75ADA
(3.13)
∗2
(1760)
∗2
2.9
1AADA
1EADA
