4.8 Dimensional Drawings of Rack-mounted SERVOPACK Model

4-29

SERVOPACK Specifications and Dimensional Drawings

4.8.6 Three-phase 200 V: 5.0 kW (50ADA-R)

(50)

(35)

CN2

CN1

CN3

YASKAWA SERVOPACK 200V

SGDM-50ADA-R

285

270

250

(7.5)

(17.5)

(7.5)

(17.5)

230

(50)

(75)

24.5

Nameplate

135

50±0.5

(7.5)

270±0.5

(83)

CHANGE

MODE/SET

DATA/

POWER

L1C

L2C

+ 1

+ 2

Mounting Hole Diagram

4×M5 tap

(Mounting pitch)

Units: mm

Approx. mass: 5.7 kg

(100°)

Heat sink

Flange

6-pin terminal

M5 screw

Ground terminal

M5 screw

5-pin terminal

M4 screw

3-pin terminal

M5 screw

External Terminal Connector

SERVOPACK Connector

Connector

Symbol

SERVOPACK

Connector Model

Manufacturer

CN1 10250-52A2JL Sumitomo 3M Co., Ltd.

CN2 53460-0611 Molex Japan Co., Ltd.

CN3 10214-52A2JL Sumitomo 3M Co., Ltd.

L1C L2CL2 L3L1

200 VAC

50/60 Hz

Three-phase

200 VAC

50/60 Hz

Single-phase

Main circuit

power supply

Control power

supply
