4 SERVOPACK Specifications and Dimensional Drawings

4.8.5 Three-phase 200 V: 2.0 kW/3.0 kW (20AD-R to 30AD-R, 20ADA-R to 30ADA-R)

4-28

4.8.5 Three-phase 200 V: 2.0 kW/3.0 kW

(20AD-R to 30AD-R, 20ADA-R to 30ADA-R)

Cooling fan

CN3

CN1

CN2

(100°)

YASKAWA

SERVOPACK

SGDM-

Nameplate

180

Heat sink

250

270

285

(15)

Flange

24.5

155.5

(7.5)

(17.5)

(7.5)

110

(75)

(40)

(30)

270 ± 0.5

50±0.5

(7.5)

14-pin terminal

M4 mounting screw

CHANGE

MODE/SET

DATA/

POWER

Mounting Hole Diagram

4×M5 tap

(Mounting pitch)

Ground terminal

2×M4 screws

Units: mm

Approx. mass: 4.0 kg

External Terminal Connector

SERVOPACK Connector

Connector

Symbol

SERVOPACK

Connector Model

Manufacturer

CN1 10250-52A2JL Sumitomo 3M Co., Ltd.

CN2 53460-0611 Molex Japan Co., Ltd.

CN3 10214-52A2JL Sumitomo 3M Co., Ltd.

L1C L2CL2 L3L1

200 VAC

50/60 Hz

Three-phase

200 VAC

50/60 Hz

Single-phase

Main circuit

power supply

Control power

supply
