3.20 Shaft End Specifications for SGMGH, SGMSH and SGMDH Servomotors

3-137

Servomotor Specifications and Dimensional Drawings

3.20.2 SGMSH Servomotors

Units: mm

Symbol Specifications

Model

SGMSH-

10 15 20 30 40 50

2Straight

LR 45 63

Q40 55

3 Taper 1/10, parallel key

LR 70 80

LW 20

Q 36 42

QA 14 18

QK 32 36

X12.5 16

S24 28

V24 30

PM12, P1.25 M16, P1.5

U 7.1 8.95

5 Taper 1/10, wood-ruff key

−−

6 Straight, with key and tap

LR 45 63

Q40 55

QK 32 50

P M8 screw, depth: 16

−0.013
