12.2 Connection to Host Controller

12-17

Appendix

12.2.3 Example of Connection to MEMOCON GL120/130 Series Motion Module

MC20

* 1. Pin numbers are the same for SV2 to SV4.

* 2. represents twisted-pair wires.

PAO

/PAO

PBO

/PBO

PCO

/PCO

VREF

V-REF

BAT

BAT(+)

BAT0

BAT(-)

+24V

+24VIN

SVON

/S-ON

PCON

/P-CON

SEN

0SEN

/ALM-RST

ALM

ALM+

ALM0

ALM -

ALM-RST

FG (Connector frame)

/PA

/PB

/PC

SGDM SERVOPACK

MEMOCON GL120/130 Series

MC20 manufactured by Yaskawa

CN2

CN1

SV1

∗1

∗2

L1C

L2C

A (1)

(2)

(3)

(4)

Servomotor
