2.3 Σ
-
II Series SERVOPACKs and Applicable Servomotors
2-15
2.3
Σ
-
II Series SERVOPACKs and Applicable Servomotors
2.3.1 SGDM SERVOPACKs and SGMH Servomotors
Note: 1. =A: 200 V, B: 100 V (Be sure to match the voltage ratio on the servomotor and the SERVOPACK.)
2. Servomotors with low-backlash gears are available.
Σ-II Series SGMH Servomotor
Σ-II Series SGDM SERVOPACK
Single-phase
100 VAC
Single-phase
200 VAC
Three-phase
200 VAC
SGMAH
(Super High Power
Capacity)
3000 min
-1
8 models
A3
(30 W)
A3BD, A3BDA A3AD, A3ADA −
A5
(50 W)
A5BD, A5BDA A5AD, A5ADA −
01
(100 W)
01BD, 01BDA 01AD, 01ADA −
02
(200 W)
02BD, 02BDA 02AD, 02ADA −
04
(400 W)
− 04AD, 04ADA −
08
(750 W)
−−08AD, 08ADA
SGMPH
(Flat Type)
3000 min
-1
5 models
01
(100 W)
01BD, 01BDA 01AD, 01ADA −
02
(200 W)
02BD, 02BDA 02AD, 02ADA −
04A (400 W) − 04AD, 04ADA −
08A (750 W) −−08AD, 08ADA
15A (1.5 kW) −−15AD, 15ADA
SGMGH
(High Speed Feed)
1500 min
-1
10 models
05A (450 W) −−05AD, 05ADA
09A (850 W) −−10AD, 10ADA
13A (1.3 kW) −−15AD, 15ADA
20A (1.8 kW) −−20AD, 20ADA
30A (2.9 kW) −−30AD, 30ADA
44A (4.4 kW) −−50ADA
55A (5.5 kW) −−60ADA
75A (7.5 kW) −−75ADA
1AA (11.0 kW) −−1AADA
1EA (15.0 kW) −−1EADA
SGMGH
(High Speed Feed)
1000 min
-1
8 models
03A (300 W) −−05ADA
06A (600 W) −−08ADA
09A (900 W) −−10ADA
12A (1.2 kW) −−15ADA
20A (2.0 kW) −−20ADA
30A (3.0 kW) −−30ADA
40A (4.0 kW) −−50ADA
55A (5.5 kW) −−60ADA
SGMSH
(Super High Power
Capacity)
3000 min
-1
6 models
10A (1.0 kW) −−10ADA
15A (1.5 kW) −−15ADA
20A (2.0 kW) −−20ADA
30A (3.0 kW) −−30ADA
40A (4.0 kW) −−50ADA
50A (5.0 kW) −−50ADA
SGMDH
(Flat Type)
2000 min
-1
3 models
22A (2.2 kW) −−30ADA
32A (3.2 kW) −−50ADA
40A (4.0 kW) −−50ADA
To Next Page
