4.7 Dimensional Drawings of Base-mounted SERVOPACK Model

4-19

SERVOPACK Specifications and Dimensional Drawings

4.7.4 Three-phase 200 V: 1.5 kW (15AD, 15ADA)

CN3

CN1

CN2

YAS KAWA

YASK AWA

SERVOPACK

SGDM-

5.5

(5)

MODE/SET

CHARGE POWER

DATA/

Heat sink

110

160

2×φ5

holes

Ground

terminal

2×M4 screws

Terminal

block

180

Nameplate

(75)

160

(5)

100 ± 0.5

110

149.5± 0.5

(Mounting pitch)

4×M4 screw holes

Mounting Hole Diagram

(5)

Cooling fan

Units: mm

Approx. mass: 2.8 kg

External Terminal Connector

SERVOPACK Connector

Connector

Symbol

SERVOPACK

Connector Model

Manufacturer

CN1 10250-52A2JL Sumitomo 3M Co., Ltd.

CN2 53460-0611 Molex Japan Co., Ltd.

CN3 10214-52A2JL Sumitomo 3M Co., Ltd.

L1C L2CL2 L3L1

Three-phase

200 VAC

50/60 Hz

Single-phase

200 VAC

50/60 Hz

Main circuit

power supply

Control power

supply
