2 Selections

2.3.2 SGDM SERVOPACKs and SGMCS Servomotors

2-16

2.3.2 SGDM SERVOPACKs and SGMCS Servomotors

The SGMCS Servomotor can be combined only with a SGDM SERVOPACK with software version 32 or later.

Note that SGMCS Servomotor can’t be used with the SGDM-D and SGDM SERVOPACK with software

version 31 or earlier.

Σ-II Series SGMCS Servomotor

Σ-II Series SGDM SERVOPACK

Single-phase 200 VAC Three-phase 200 VAC

SGMCS

(Direct-drive series)

150 min

-1

8 models

200 min

-1

9 models

02B

02ADA −

05B

02ADA −

07B

02ADA −

04C

04ADA −

10C

04ADA −

14C

04ADA −

08D

04ADA −

17D

04ADA −

25D

04ADA −

16E

− 08ADA

35E

− 08ADA

45M

− 10ADA

80M

− 15ADA

1AM

− 20ADA

80N

− 15ADA

1EN

− 30ADA

2ZN

− 30ADA
