3 Servomotor Specifications and Dimensional Drawings

3.20.3 SGMDH Servomotors

3-138

3.20.3 SGMDH Servomotors

Units: mm

Symbol Specifications

Model

SGMDH-

22 32 40

2 Straight

LR 55 65

Q50 60

3 Taper 1/10, parallel key

LR −−

LW −−

Q −−

QA −−

QK −−

X −−

S −−

V −−

P −−

W −−

T −−

U −−

5 Taper 1/10, wood-ruff key

−−

6 Straight, with key and tap

LR 55 65

Q50 60

QK 45 50

W8 10

T7 8

U4 5

P M8 screw, depth: 16 M12 screw, depth: 25

−0.013

−0.016

−0.013

−0.016
