3 Servomotor Specifications and Dimensional Drawings
3.19.5 SGMCS Servomotors φ280 Model
3-130
3.19.5 SGMCS Servomotors φ280 Model
(1) Applicable flange: 1
(2) Applicable flange: 3
Model
SGMCS-
LL KB1 KB2
Approx. Mass
kg
45MA11
141 87.5 122 38
80MA11
191 137.5 172 45
1AMA11
241 187.5 222 51
A
15
φ140
147
182
15
(within φ280h7)
φ280h7 φ110h7
15
(within φ75H6)
φ264
41
φ88
0.04
B
AB
0.08
AB
12
×M6 screw, depth 15
30
°
KB2
KB1
φ75.2
LL
6
5
φ280±0.5
φ115
φ250
1.5
Rotating
Section
φ75H6
(Rotating
Section)
Rotating Section
(shown with hatching)
Rotating Section
(shown with
hatching)
12×M6 screw, depth 18
Units: mm
φ75H6: φ75
+0.019
0
φ280h7: φ280
-0.052
0
φ110h7: φ110
0
-0.035
0.04
φ0.08
(Divided into equal sections)
(Divided into equal sections)
5
182
15LL
6
KB2
KB1
L
41
1.5
0.08
C
AB0.08
φ
75H6
φ
115
φ
75.2
φ
280
φ
110h7
φ
248h7
φ
140
φ
15
(within
75H6
)
φ
88
φ
10
°
147
264
φ
C
0.02
A
0.04
B
0.04
Units: mm
12 × M6 screw, depth 15
12
× M6
screw, depth 15
(shown with hatching)
Rotating section
Rotating
Section
(shown
with
hatching)
φ75H6: φ75
+0.019
0
φ110h7: φ110
-0.035
0
φ248h7: φ248
0
-0.046
( Divided into equal sections )
(
Divided into equal
sections
)
Model
SGMCS-
L LL KB1 KB2
Approx. Mass
kg
45M

A31
150 135 102.5 137 38
80M

A31
200 185 152.5 187 45
1AM

A31
250 235 202.5 237 51
