3 Servomotor Specifications and Dimensional Drawings
3-46
3.11 Servomotor Dimensional Drawings
Dimensional drawings for the SGM servomotors are broadly grouped using the following categories: With or
without gears or brakes.
Note: Servomotors SGMDH (2000min
-1
) and SGMCS (direct-drive series) do not have any models pro-
vided with gears.
Series Motor Capacity Groups of Servomotor Dimensional Drawings
Refer-
ence
SGMAH
(3000 min
-1
)
100 VAC:
0.03, 0.05, 0.1, 0.2 kW
200 VAC:
0.03, 0.05, 0.1, 0.2, 0.4, 0.75 kW
Without gears and brakes
3.12.1
With brakes
3.12.2
With standard backlash gears
3.12.3
With standard backlash gears and brakes
3.12.4
With low-backlash gears
3.12.5
SGMPH
(3000 min
-1
)
100 VAC
0.1, 0.2 kW
200 VAC
0.1, 0.2, 0.4, 0.75, 1.5 kW
Without gears and brakes
3.13.1
With brakes
3.13.2
With standard backlash gears
3.13.3
With standard backlash gears and brakes
3.13.4
With low-backlash gears
3.13.5
SGMGH
(1500 min
-1
)
200 VAC:
0.45, 0.85, 1.3, 1.8, 2.9, 4.4, 5.5,
7.5, 11.0, 15.0 kW
Without gears and brakes
3.15.1
With brakes
3.15.2
Foot-mounted type with standard backlash gears
3.15.3
Flange-type with standard backlash gears
3.15.4
Flange-type with low-backlash gears
3.15.5
SGMGH
(1000 min
-1
)
200 VAC:
0.3, 0.6, 0.9, 1.2, 2.0, 3.0, 4.0,
5.5 kW
Without gears and brakes
3.16.1
With brakes
3.16.2
Foot-mounted type with standard backlash gears
3.16.3
Flange-type with standard backlash gears
3.16.4
Flange-type with low-backlash gears
3.16.5
SGMSH
(3000 min
-1
)
200 VAC:
1.0, 1.5, 2.0, 3.0, 4.0, 5.0 kW
Without gears and brakes
3.17.1
With brakes
3.17.2
Flange-type with low-backlash gears
3.17.3
SGMDH
(2000 min
-1
)
200 VAC:
2.2, 3.2, 4.0 kW
Without gears and brakes
3.18.1
With brakes
3.18.1
SGMCS
200 VAC (small-capacity):
2, 5, 7, 4, 10, 14, 8, 17, 25, 16, 35
Nxm
200 VAC (middle-capacity):
45, 80, 110, 150, 200 Nxm
φ135 model
3.19.1
φ175 model
3.19.2
φ230 model
3.19.3
φ290 model
3.19.4
φ280 model
3.19.5
φ360 model
3.19.6
To Next Page
