5.8 Peripheral Devices
5-71
5
Specifications and Dimensional Drawings of Cables and Peripheral Devices
5.8.10 Noise Filter
The noise filters model FN and FS manufactured by Schaffner Electronic and FMAC manufacture by Timonta
AG are recommended. Contact Yaskawa Controls Co., Ltd.
Select one of the following noise filters according to SERVOPACK capacity. For more details, refer to 2.5.3
Noise Filters, Magnetic Conductors, Surge Absorbers and DC Reactors.
Refer to 6.1.3 Typical Main Circuit Wiring Examples for the connection method.
(1) Single-phase, 100/200 V
Model
FN2070
-6/07
FN2070
-10/07
FN2070-16/07 FN350-30/33
Dimensional
Drawings
External
Dimensions
in mm
Symbol Dimensions Dimensions
A
113.5 ± 1 156 ± 1 119 ± 0.5
A
105 ± 0.5
B
57.5 ± 1 85.5 ± 1
B
99.5 ± 0.5
C
45.4 ± 1.2 57.6 ± 1
C
57 ± 1
D
94 ± 1 130.5 ± 1 98.5 ± 1
D
84.5 ± 1
F
103 ± 0.3 143 ± 0.3 109 ± 0.3
E
79 ± 0.5
J
25 ± 0.2 40 ± 0.2
J
95 ± 0.2
K
8.4 ± 0.5 8.6 ± 0.5
K
51 ± 0.1
L
32.4 ± 0.5 −
L
−
M
4.4 ± 0.1 5.3 ± 0.1 4.4 ± 0.1
M
19 ± 0.5
N
6 ± 0.1 7.4 ± 0.1
N
−
P
0.
9 ± 0.1 1.2 ± 0.1
P
4.4 ± 0.1
Q
− 66 ± 0.3
Q
6 ± 0.1
R
− 51 ± 0.2
R
−
S
38 ± 0.5 −
S
−
Specifications
250 VAC,
6 A
250 VAC,
10 A
250 VAC, 16 A
250 VAC,
30 A
Applicable
SERVOPACK
SGDM-
Single-
phase
100 V
A3BD, A3BDA
A5BD, A5BDA
01BD, 01BDA
02BD, 02BDA −−
Single-
phase
200 V
A3AD, A3ADA
A5AD, A5ADA
01AD, 01ADA
02AD, 02ADA
04AD, 04ADA −−
Manufacturer
Schaffner Electronic
Contact Terminal
P/N/E
140
-0
+5
To Next Page
