4 SERVOPACK Specifications and Dimensional Drawings
4.8.1 Single-phase 100 V: 30 W/50 W/100 W (A3BD-R to 01BD-R, A3BDA-R to 01BDA-R) Single-phase 200 V: 30 W/50 W/100 W/200 W
(A3AD-R to 02AD-R, A3ADA-R to 02ADA-R)
4-24
4.8 Dimensional Drawings of Rack-mounted SERVOPACK Model
4.8.1 Single-phase 100 V: 30 W/50 W/100 W
(A3BD-R to 01BD-R, A3BDA-R to 01BDA-R)
Single-phase 200 V: 30 W/50 W/100 W/200 W
(A3AD-R to 02AD-R, A3ADA-R to 02ADA-R)
CN3
CN2
CN1
6
YASKAWA SERVOPACK
SGDM-
6
180
160
195
17.5
7.5
17.5
55
10
5
42
1.5
22.5
φ
160
130
55
22.5
7.5
180±0.5
10
2
17
(7.5)
(11.5)
(32.5)
5 hole
24.5
(75)
(7.5)
(10)
(32.5)
Min.166
YAS KAWA
CHANGE
L1
C
N
3
L2
L2C
B1
B2
U
V
W
L1C
POWER
+ 1
+ 2
C
N
1
C
N
2
MODE/SET
DATA/
Ground terminal
2×M4 screws
Nameplate
Mounting Hole Diagram
2×M4 screw holes
(Mounting pitch)
Units: mm
Approx. mass: 1.0 kg
Terminal
block
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
L1 L2
Main circuit
power supply
Control power
supply
Single-phase
100/200 VAC
50/60 Hz
L1C L2C
Single-phase
100/200 VAC
50/60 Hz
