5.2 Servomotor Main Circuit Wire Size and Connectors

5-27

Specifications and Dimensional Drawings of Cables and Peripheral Devices

(3) Servomotor Main Circuit Connector Pin Arrangement

(a) Without Brakes

(b) With Brakes

1.0 to 5.0 kW

Servomotor-end

connector

Servomotor Connector Pin Arrangement

Phase U

Phase V

Phase W

FG (Frame Ground)

Pin No. Signal

1.0 to 5.0 kW

Servomotor-end

connector

Servomotor Connector Pin Arrangement

Phase U

Phase V

Phase W

FG (Frame Ground)

Pin No. Signal

E *

F *

Brake terminal

Pin No. Signal

* No polarity
