YASKAWA Sigma II Series User Manual

5 Specifications and Dimensional Drawings of Cables and Peripheral Devices
5.2.13 Connector Dimensional Drawings
5-32
(c) L-shaped Plugs
Note: The plug CE05-8A-P-B-BAS is pin inserting type. The mating receptacle is socket inserting type.
(d) Plug
Note: 1. The plug CE05-6A-P-B is pin inserting type. The mating receptacle is socket inserting type.
2. Consult the conduit manufacturer if a conduit is required.
Positioning key
V screw
A
L
R
φQ
(S)
V
W
U
Units: mm
Model
Joint Screw
A
Outer
Diameter of
Nut
φQ
Max.
Overall
Length
L
Cable Clamp
Mounting Screw
V
R±0.7 U±0.7 (S)±1
Effective
Screw
Length
W
CE05-8A10SL-3SC-B-BAS 5/8-24UNEF-2B
22.22
47.8
5/8-24UNEF-2A
7.9 21.0 28.9 7.5
CE05-8A18-10SD-B-BAS 1 1/8-18UNEF-2B
34.13
69.5
1-20UNEF-2A
13.2 30.2 43.4 7.5
+0
-0.38
Gasket
A screw
(J)
E
LH
φQ
φB
V screw
Positioning key
Units: mm
Model
Joint Screw
A
Outer Diameter
of Nut
φQ
Overall
Length
L±1
Conduit
Mounting
Screw
V
E±0.5
φB
H±0.1
(J)
CE05-6A10SL-3SC-B
5/8-24UNEF-2B
22.22
23.3 9/16-24UNEF-2A 7.5 12.5 5.6 13.2
CE05-6A18-10SD-B
1 1/8-18UNEF-2B
34.13
33.7 1-20UNEF-2A 11.74 23.5 6.4 19.0
+0
-0.38
+0.05
-0.25
