5 Specifications and Dimensional Drawings of Cables and Peripheral Devices

5.4.6 Encoder Flexible Cables for SGMGH, SGMSH, and SGMDH Servomotors

5-46

17-bit Absolute Encoder Connection Specifications 17-bit Incremental Encoder Connection Specifications

Pin No. Signal

Wire

Marker

Lead

Color

Pin No. Signal

Wire

Marker

Lead

Color

−−−

PS 5

Red/light

blue

PS 5

Red/light

blue

/PS 6

Black/light

blue

/PS 6

Black/light

blue

−−−

PG0V 2 Green

PG5V 1 Orange

FG (Frame Ground) Shield wire

−−−

BAT(−) 4 Black/pink

−−−

BAT(+) 3 Red/pink

−−−
