5.7 I/O Signal Cables for CN1 Connector

5-57

Specifications and Dimensional Drawings of Cables and Peripheral Devices

(2) Dimensional Drawing of Connector

(3) Cable Size

2.54

Units: mm

1.27

Pin No. 26

Pin No. 1

36.7

30.48

15q

1.27

41.1

5.1

(6.6)

19.3

(2.9)

2.3

12.7

㧟㧹

9.1

7.5

Pin No. 2

Item Specifications

Cable Use twisted-pair or twisted-pair shielded wire.

Applicable Wires AWG24, 26, 28, 30

Finished Dimension φ16 mm or less
