Quick access to your required information
Read the chapters marked with 9 to get the information required for your purpose.
■
Visual Aids
The following aids are used to indicate certain types of information for easier reference.
• Indicates important information that should be memorized, including precautions such as alarm dis-
plays to avoid damaging the devices.
• Indicates supplemental information.
• Indicates application examples.
• Indicates definitions of difficult terms or terms that have not been previously explained in this man-
ual.
Chapter
SERVOPACKs,
Servomotors,
and Peripheral
Devices
Ratings and
Character-
istics
System
Design
Panel
Configura-tion
and Wiring
Trial Operation
and Servo
Adjustment
Inspection and
Maintenance
Chapter 1
Outline
9
Chapter 2
Selections
9
Chapter 3
Servomotor Specifications
and Dimensional Drawings
9999
Chapter 4
SERVOPACK Specifications
and Dimensional Drawings
9999
Chapter 5
Specifications and
Dimensional Drawings of
Cables and Peripheral
Devices
9999
Chapter 6
Wiring
99 9
Chapter 7
Digital Operator/Panel
Operator
99
Chapter 8
Operation
9
Chapter 9
Adjustments
9
Chapter 10
Upgraded Versions
9999
Chapter 11
Inspection, Maintenance,
and Troubleshooting
9
Chapter 12
Appendix
9999
