8 Operation

8.6.3 Position Reference

8-56

When the external power supply is used, the circuit will be isolated by a photocoupler. When the SERVO-

PACK internal power supply is used, the circuit will not be isolated.

* : Represents twisted-pair wires.

When the open-collector output is used, input signal noise margin lowers. When a position error caused by

the noise occurs, set the parameter Pn200.3 to 1.

(3) Position Control Block Diagram

A block diagram for position control is shown below.

CN1

/PULS

SIGN

/SIGN

CLR

/CLR

PULS

PL1

PL2

PL3

150Ω

1kΩ

+12V

∗

Tr1

1.5 V max. at ON

SERVOPACKHost controller

Photocoupler

IMPORTANT

Pn201

Pn204

Pn202

Pn203

Pn102

Pn203

Pn202

Pn10A

Pn107

Pn109

Pn200.0

Pn108

Differ-

ential

Smoothing

Error

counter

Feed-

forward

Feed-for-

ward fil-

ter time

constant

Bias

Speed

loop

Current

loop

Dividing

Servomotor

Reference

pulse

PG signal

output

SERVOPACK (in position control)

Encoder

Bias adding

width

× 4

× 2

× 1
