3.1 Ratings and Specifications of SGMAH (3000 min
-1
)
3-7
3
Servomotor Specifications and Dimensional Drawings
* 1. Maximum motor speed is up to 4000 min
-1
at the shaft.
* 2. Gear output torque is expressed using the following equation.
(Gear output torque) = (servomotor output torque) × × (efficiency)
The no-load torque for a servomotor with gears is high immediately after the servomotor starts, and it then
decreases and becomes stable a few minutes later. This is a common phenomenon caused by grease being
circulated in the gear and not by a faulty gear.
The speed control range of SERVOPACKs in the Σ-II series is 1:5000. When using servomotors at
extremely low speeds (for example, 0.02 min
-1
max. at the gear output shaft) or when using servomotors
with one pulse feed reference for extended periods and in other situations that are less than optimum, the
lubrication of the gear bearing may be insufficient. This may cause deterioration of the bearing or increase
the load ratio.
Contact your Yaskawa representative if you are using your servomotor under such conditions.
Servomotor
Model
SGMAH-
Servomotor Gear Output
Moment of Inertia J
×10
-4
kg·m
2
Out-
put
W
Rated
Speed
min
-1
Rated
Torque
Nxm
Gear
Ratio
Rated
Torque/
Effi-
ciency
∗
2
N·m/%
Instanta-
neous
Peak
Tor que
N·m
Rated
Speed
min
-1
Max.
Speed
∗1
min
-1
Motor +
Gears
Gears
A3AJ1
30
3000
0.0955
1/5 0.238/50 1.16 600 800 0.044 0.028
A3AJ3
3/31 0.687/70 2.37 290 387 0.033 0.016
A3AJC
1/21 1.60/80 5.48 143 190 0.023 0.007
A3AJ7
1/33 2.51/80 8.61 91 121 0.021 0.005
A5AJ1
50 0.159
1/5 0.557/70 1.92 600 800 0.050 0.028
A5AJ3
3/31 1.15/70 3.95 290 387 0.040 0.018
A5AJC
1/21 2.67/80 9.07 143 190 0.036 0.014
A5AJ7
1/33 4.20/80 14.3 91 121 0.032 0.010
01AJ1
100 0.318
1/5 1.27/80 4.32 600 800 0.099 0.063
01AJ3
3/31 2.63/80 8.88 290 387 0.054 0.018
01AJC
1/21 5.34/80 18.1 143 190 0.071 0.035
01AJ7
1/33 8.40/80 28.4 91 121 0.057 0.021
02AJ1
200 0.637
1/5 2.55/80 8.60 600 800 0.299 0.193
02AJ3
3/31 5.27/80 17.8 290 387 0.196 0.090
02AJC
1/21 10.7/80 36.1 143 190 0.211 0.105
02AJ7
1/33 16.8/80 56.7 91 121 0.181 0.075
04AAJ1
400 1.27
1/5 5.08/80 17.2 600 800 0.366 0.193
04AAJ3
3/31 10.5/80 35.5 290 387 0.353 0.180
04AAJC
1/21
21.3/80 72.2 143 190 0.403 0.230
04AAJ7
1/33 33.5/80 113.0 91 121 0.338 0.165
08AAJ1
750 2.39
1/5 9.56/80 32 600 800 1.12 0.450
08AAJ3
3/31 19.8/80 66.6 290 387 1.10 0.425
08AAJC
1/21 40.2/80 134 143 190 1.15 0.475
08AAJ7
1/33 63.1/80 213 91 121 0.972 0.300
1
gear ratio
( )
IMPORTANT
