3 Servomotor Specifications and Dimensional Drawings

3.2.1 SGMPH Servomotors Without Gears

3-12

(5) Holding Brake Electrical Specifications

Note: The holding brake is only used to hold the load and cannot be used to stop the servomotor.

Holding

Brake Rated

Voltage

Servomotor

Model

Servomotor

Capacity

Holding Brake Specifications

Capacity

Holding

Tor q ue

N·m

Coil

Resistance

Ω (at 20 °C)

Rated

Current

A (at 20 °C)

90 VDC

SGMPH-01 100 8.1 0.318 1000 0.09

SGMPH-02 200 7.6 0.637 1062 0.085

SGMPH-04 400 7.2 1.27 1125 0.08

SGMPH-08 750 7.5 2.39 1083 0.083

SGMPH-15 1500 10 4.77 832 0.108

24 VDC

SGMPH-01 100 6 0.318 114 0.25

SGMPH-02 200 5 0.637 115 0.21

SGMPH-04 400 7.6 1.27 76 0.32

SGMPH-08 750 7.5 2.39 76.8 0.31

SGMPH-15 1500 10 4.77 57.6 0.42
