3.3 Ratings and Specifications of SGMGH (1500 min
-1
)
3-17
3
Servomotor Specifications and Dimensional Drawings
(4) Holding Brake Electrical Specifications
Note: The holding brake is only used to hold the load and cannot be used to stop the servomotor.
Holding
Brake Rated
Voltage
Servomotor
Model
Servomotor
Capacity
W
Holding Brake Specifications
Capacity
W
Holding
Tor que
N·m
Coil
Resistance
Ω (at 20 °C)
Rated
Current
A (at 20 °C)
90 VDC
SGMGH-05 450 10.1 4.41 804 0.11
SGMGH-09 850 10.1 12.7 804 0.11
SGMGH-13 1300 10.1 12.7 804 0.11
SGMGH-20 1800 18.5 43.1 438 0.21
SGMGH-30 2900 18.5 43.1 438 0.21
SGMGH-44 4400 18.5 43.1 438 0.21
SGMGH-55 5500 23.5 72.6 327 0.28
SGMGH-75 7500 23.5 72.6 327 0.28
SGMGH-1A 11000 32.0 84.3 253 0.36
SGMGH-1E 15000 35.0 115 231 0.39
24 VDC
SGMGH-05 450 9.85 4.41 58.7 0.41
SGMGH-09 850 9.85 12.7 58.7 0.41
SGMGH-13 1300 9.85 12.7 58.7 0.41
SGMGH-20 1800 18.5 43.1 31.1 0.77
SGMGH-30 2900 18.5 43.1 31.1 0.77
SGMGH-44 4400 18.5 43.1 31.1 0.77
SGMGH-55 5500 23.5 72.6 24.5 0.98
SGMGH-75 7500 23.5 72.6 24.5 0.98
SGMGH-1A 11000 32.0 84.3 18.0 1.33
SGMGH-1E 15000 35.0 115 16.4 1.46
