Zebra ZM400 Series User Manual

445
Drawings and Parts
Media and Ribbon Path
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Table D • Media and Ribbon Path
1
79839M
ZM400 Media Hanger Maintenance Kit, see page 446 for kit content
information
1
79840M
ZM600 Media Hanger Maintenance Kit, see page 446 for kit content
information
1
2
79854M
ZM400 Static Brush Maintenance Kit, see page 454 for kit content
information
1
79855M
ZM600 Static Brush Maintenance Kit, see page 454 for kit content
information
1
3
G77100M
ZM400 Ribbon Take-up Spindle Maintenance Kit, see page 455 for kit
content information
1
G77117M
ZM600 Ribbon Take-up Spindle Maintenance Kit, see page 455 for kit
content information
1
4
79848M
ZM400 Media Sensor Maintenance Kit, see page 447 for kit content
information
1
79849M
ZM600 Media Sensor Maintenance Kit, see page 447 for kit content
information
1
5
79821M
ZM400/ZM600 Head Open/Ribbon Sensor Maintenance Kit 1
6
79828M
ZM400 Ribbon Supply Spindle, see page 448 for kit content information 1
79829M
ZM600 Ribbon Supply Spindle, see page 448 for kit content information 1
7
Ref
ZM400/ZM600 Platen Housing Maintenance Kit, see page 453 for further
information
1
8
Ref
ZM400/ZM600 Print Mechanism Maintenance Kit, see page 449 for kit
content information
1
Bold = Part available for purchase
Light italic = Part not available for individual purchase, listed and shown for reference only
Boxes = Parts contained in kits listed above

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
