Allied Telesis SwitchBlade x3100 Series User Manual

Introduction Configuring Port Based HVLAN
Software Reference for SwitchBlade x3100 Series Switches (Layer Two Switching)
4-188
4.9.3.3 Configuration Procedure
TABLE 4-27 Configuration Procedure for Port Based HVLAN
Step Command Description
Create the port-based HVLAN
1
CREATE HVLAN=H_100 VID=100 TYPE=PORT-
TUNNEL
Creates a port-based VLAN tunnel.
Set the Network interfaces to a TPID value
2
SET INTERFACE=0.1,0.2 TPID=0x9100 Set this only when sure that the Network inter-
face is expecting this value.
Note: This step is only needed when connecting
to a non-Allied Telesis device.
Associate HVLAN with Network interfaces.
3
ADD HVLAN=H_100 INTERFACE=0.1,0.2
FRAME=TAGGED
Adds a tagged HVLAN to Network interfaces.
Associate HVLAN with line card ports.
4
ADD HVLAN=H_100 INTERFACE=2.0,2.1
FRAME=UNTAGGED
Adds an untagged HVLAN to Customer inter-
faces.
Disable IGMP and DHCP on the customer interfaces
5
DISABLE IGMP INTERFACE=2.0,2.1
DISABLE DHCP ALL INTERFACE=2.0,2.1
On Customer interfaces, ensure IGMP and DHCP
are correctly configured.
Set line card interface to TAGALL=ON
6
SET INTERFACE=2.0,2.1 TAGALL=ON
Observe the configuration
7
SHOW HVLAN FULL
--- HVLAN Information ---------------------------
Type.................................. HVLAN - port tunnel
Name.................................. H_100
Identifier............................ 100
Status................................ static
Forwarding Mode....................... Standard
IP module attached....................
Untagged interfaces................... ETH:[2.0,2.1]
Tagged interfaces..................... ETH:[0.1,0.2]
Tunneled VLANs........................ n/a
