Software Reference for SwitchBlade x3100 Series Switches (Access and Security)

6-10

[IPSOURCE={ipaddress-mask|ANY}] The source IP address (either host or subnet) of the IP packet.

IP address ranges are specified using a valid IP address or valid subnet and

mask. A range is specified using a ‘/’ character (such as 1.0.0.0/8).

ANY - match all IP packets with any IPSOURCE value.

[IPDSCP={0..63|ANY}] The code point field with the DiffServ byte of an IP packet. This parameter

cannot be specified with the IPTOS parameter.

ANY - match all IP packets with any IPDSCP value.

[IPPROTOCOL={TCP|UDP|ICMP|IGMP|

ipprotocol-number|ANY}]

The layer 4 IP protocol of the IP packet.

If the command specifies a TCP/IP packet matching rule, (e.g. TCPPORT-

DESC is specified), then the value for this parameter will be TCP. If the

command specifies a UDP/IP packet matching rule, (i.e. the UDPPORT-

DESC parameter is specified), then the value for this parameter will be

UDP.

ipprotocol-number is expressed a one byte hexadecimal or decimal num-

ber.

ANY - match any layer 4 IP protocol.

[MACDEST={macaddress|MULTI-

CAST|ANY}]

The destination MAC address for the packet. MULTICAST is for multicast

packets.

ANY - match all packets with any MACDEST value.

[MACSOURCE={macaddress|ANY}] The source MAC address.

ANY - match all packets with any MACSOURCE value.

[PROTOCOL=

{IPV4|IPV6|protocol-type|ANY}]

The type field of the payload.

ANY - match all IP packets with any PROTOCOL value.

[TCPPORTDEST={tcp-port|ANY}] The TCP destination port of a TCP/IP packet.

ANY - match all IP packets with any TCPPORTDEST value.

[TCPPORTSOURCE={tcp-port|ANY}] The TCP source port of a TCP/IP packet.

ANY - match all IP packets with any TCPPORTSOURCE value.

TABLE 6-2 Classifiers (Continued)Match Rules

Parameter Description

Allied Telesis SwitchBlade x3100 Series User Manual
