Introduction Configuring LLDP
Software Reference for SwitchBlade x3100 Series Switches (Network Management)
7-80
SYSDESC System Description The configured value describing the system (The “Location” field in
the show system CLI command)
SYSCAP System Capabilities the system’s capabilities and its primary network function (4=Bridge
Capability Supported)
PORTVLAN Port VLAN Identi-
fier (PVID)
The default VID value associated with the network port for received
untagged frames if one exists else it is set to zero (0).
VLANNAME VLAN Name VLAN ID (VID) - The default VID value associated with the network
port for received untagged frames if one exists. Otherwise it is set
to zero (0).
VLAN Name Length - The VLAN name length in bytes
VLAN NAME - The configured VLAN Name
PROTOVLAN Port and Protocol
VLAN ID
Flag - Bit 1:
- 0 (Port and protocol VLAN not supported)
Flag - Bit 2:
- 0 (Port and protocol VLAN not enabled)
Flags - Bits 3 through 8:
- 0 (Reserved for future use)
Port and Protocol VLAN ID (PPVID):
- 0 (Valid value when flags above indicates port and protocol VLAN
is not supported and not enabled).
PROTOCOL Protocol Identity - Protocol Identity Length - The length of the Protocol Identity field
below in bytes.
- The number of bytes (indicated by the protocol identity length field
above) whose values identify the protocol that is being advertised.
For example, when advertising the STP protocol the TLV field values
are:
- Protocol Identity Length: 8 bytes
- Protocol Identity:
- Bytes 0 and 1 – xSTP length field
- Bytes 2, 3 and 4 – LLC header bytes
- Bytes 5 and 6 – xSTP Protocol ID
- Byte 7 – xSTP Protocol Version
TABLE 7-11 Interface Protocol Configuration Options for Outgoing LLDPDU
Parameter Meaning Fields - Description
