Allied Telesis SwitchBlade x3100 Series User Manual

Configuring LLDP Introduction
7-81
Software Reference for SwitchBlade x3100 Series Switches (Network Management)
MACPHYCONFIGSTA-
TUS
Auto-negotiation
Support/Status
Bit 0:
0 (If port auto-neg not supported)
1 (If port auto-neg is supported)
Bit 1:
0 (If port auto-neg is not enabled)
1 (If port auto-neg is enabled)
Bits 2 to 7:
0 (Reserved for future use)
POWERVIAMDI MDI Power Sup-
port
Bit 0:
1 (PSE: Powered Sourcing Equip.)
Bit 1:
0 (Not Supported)
Bit 2:
0 (Disabled)
Bit 3:
0 (Pair selection cannot be controlled)
Bits 4 through &:
0 (Reserved for future use)
LINKAGGREGATION Aggregation Status Bit 0:
0 (If port cannot be aggregated)
1 (If port can be aggregated)
Bit 1:
0 (If currently not in aggregation)
1 ( If currently in aggregation)
Bits 2 through 7:
0 (Reserved for future use)
MAXFRAMESIZE Maximum 802.3
Frame Size
1522 – Indicates the support of both tagged and untagged frames.
EPSR EPSR attributes Attributes for each EPSR domain (Node type, Interface type, pro-
tected VLANs
UCP UCP attributes Attributes for the Upstream Control Protocol
ALL Include all options
TABLE 7-11 Interface Protocol Configuration Options for Outgoing LLDPDU
Parameter Meaning Fields - Description
