LNB Frequency
LNB Frequency
LNB Voltage
LNB Voltage – select the output voltage from the dropdown box
Roll Off
Choose roll off percentage. Values available depend on module type.
22kHz Tone
Switch the 22kHz output signal on or off
Depending on the hardware version and licensing, some parameters may not be available.
PL Scrambling:
Sequence Type
Multistream PLS (Physical Layer Scrambling). PLS is often referred to as the ‘gold’
or ‘root’ code and will be provided by your content provider if required.
Sequence Index
Default value is 0
PLP De-Encapsulation section:
Port ID
Specify the Port ID for T2MI stream
PID
This is T2MI stream PID
PLP ID
This is T2MI stream PLP ID of the required stream
Mode
Select one of the following modes:
o DVB
o DVB (SDT)
o MPEG
o ATSC
o OFF
De-jitter
PCR dejitter will be default on when enabling a new de-encapsulation. The user can
choose to specify the PCR PID and to do CBR dejitter if transparent output routing
CBR if transparent
This de-jitter mechanism will use the incoming CBR total bitrate as a guide for the
clock source of the stream. This is only valid for transparent mapped and PID
imported outputs
Preferred PCR pid
This allows you to set a PCR PID in the input multiplex as a priority to use for de-
jittering. If this PID is not available, then the next valid detected PCR will be used.
This is only valid for transparently mapped streams.
Reduced Input buffer
size
Enable or disable Reduced Input Buffer for introducing a low latency dejitter
function.
