– Place drip tray for workshop hoist - VAS 6208- beneath en‐
gine.
– Detach coolant hose -arrow- (bottom left) from radiator.
– Additionally detach coolant hose at engine oil cooler -arrow-
and allow coolant to drain off.
– Disconnect coolant hoses -arrows- at ATF cooler and drain off
remaining coolant.
– Unscrew bolts -arrows- and swivel ATF cooler downwards
(with lines still connected).
Audi A8 2003 ➤
Electrical system - Edition 08.2014
12 Rep. gr.27 - Starter, current supply, CCS
