BST CCD CAM 100 User Manual

Operation
9
CCD CAM 100 – Installation and Operating Manual 135/198
9.8.5.1 Selecting the Edge
Up to eight edges can be defined when operating the CCD camera
on the CAN bus. Each edge is defined with an own menu (Definition
Edge 1…8).
Selecting the edge selection
1. Call up the Definition Edge [1..8] menu.
The Definition Edge selection window appears in the display.
2. Set the desired edge number (1 ... 8) using the arrow buttons.
3. Confirm the selection with the button.
The Definition Edge menu for the edge selected appears in the
display.
