BST CCD CAM 100 User Manual

Technical Specifications
4
CCD CAM 100 – Installation and Operating Manual 35/198
Sensor
Type 4-line CCD sensor with
- 3-line CCD-RGB color sensor
- 1 line black / white sensor
Resolution Physical 10,680pixels
Interpolated 64,080pixels
SUB-pixel resolution max. 6-fold
Scanning rate max. 10kHz
Sensitivity Spectral sensitivity 400…800nm
Maximum sensitivity 550nm
Lens
Type Zoom lens
Focal length variable, 20…55mm
Format factor (crop factor) 1.25
Graphic Display
Type Touchscreen color display
Resolution 320x240pixels
Active display area 58.6mmx46.5mm
Illumination LED background lighting
CAN Bus Interface (X100, X101)
Voltage 24V⎓ (corresponds to the
supply voltage)
Transfer rate 500kBit/s,
no galvanic isolation
Terminating resistor 120Ω,
can be switched off via setup
menu
Connection 4-pin micro-style connector M8
(DIN IEC 61076)
Max. length of connecting cable 20m
External Illumination (X70)
Voltage max. 24V⎓
Current max. 500mA
Connection 6-pin micro-style connector M8
(DIN IEC 61076)

BST CCD CAM 100 Specifications

General

Brand	BST
Model	CCD CAM 100
Category	Accessories
Language	English
